System Requirements
Windows
Windows 7x 64/x86 SP1 or Windows 8/8.1 x64/x86 or Windows 10 x64/x86
Intel Core 2 processor (Intel Core i3 processor or better recommended)
4 GB RAM (8 GB or more recommended)
Mac
Mac OS X 10.8.5 or later
Intel Core Duo processor (Intel Core 2 Duo or Intel Core i3 or better recommended)
2 GB RAM (4 GB or more recommended)
Windows and Mac Systems
USB 2.0 Port
Internet connection (only for activation)
DVD-ROM drive
Monitor with at least 1024x768 resolution
20 GB hard-disk space
Internal or external 7200 RPM storage drive highly recommended
The minimum system requirements may differ for DAWs other than Studio One (please check the requirements for your DAW of choice with its manufacturer)
System Requirements for Studio One Artist
Mac: Mac OS X 10.4.11 or Mac OS X 10.5.2 or higher, PowerPC G4 1.25 GHz or Intel Core Solo 1.5 GHz processor, 1GB RAM
Recommended: PowerPC G5 or better or Intel Core Duo or Intel Xeon processor or better, 2GB or more RAM
Win: Windows XP or Vista, Intel Pentium 4 1.6GHz processor or AMD Athlon 64 (Turion), 1GB RAM
Recommended: Intel Pentium 4 2.8GHz EM64T or better or AMD Athlon 64 3000+ or better, 2GB or more RAM
Windows and Macintosh Systems: Internet connection, DVD-ROM drive, a monitor resolution no lower than 1024x768 pixels
Microphone Preamp
Type: XLR female balanced
Frequency response (±3.0 dB): 14 Hz to 70 kHz
Input impedance (balanced): 1200 ohms
THD+N (unwtd, 1kHz at +4 dBu output, unity gain): < 0.008%
EIN (A-weighted, 55dB Gain, 150 ohms Input, 20 Hz to 22 kHz): -115 dBu
S/N ratio (Unity Gain, Ref. = +4 dBu, 20 Hz to 22 kHz): > 95 dB
Common mode rejection ratio (1 kHz, 55 dB gain): > 45 dB
Gain control range (±1 dB): 0dB to 35 dB
Max input level (unity gain, 1 kHz at 0.5% THD+N): -3 dBu
Phantom power (±2 VDC): +48 VDC
Instrument Input
Type: 1/4 in.
TRS female unbalanced input impedance: 0.5 megohm
Line Outputs
Type: 1/4 in. TRS
Balanced output impedance: 51 megohms
Headphone Output
Type: 1/4 in. TRS active stereo
Maximum output: 60 mW/Ch at 60 ohm load
Frequency Response: (±1.0 dB): 20Hz ” 30kHz
MIDI I/O
Type: Dual 5-pin female DIN
Digital Audio
ADC dynamic range (Awtd, 48kHz sample rate): 102 dB
DAC dynamic range (Awtd, 48kHz sample rate): 110 dB
Bit depth: 24
Reference level for 0dBFS: +4 dBu
Internal sample frequency selections (kHz): 44.1, 48
