• Phantom power : +48 V
• Mono[MIC/LINE] : 4
• Stereo[LINE] : 3
• STEREO OUT : 2
• MONITOR OUT : 1
• PHONES : 1
• AUX SEND : 1
• Bus - Stereo: 1, AUX[FX]: 1
• PAD : 26 dB (Mono)
• HPF : 80 Hz, 12 dB/oct (Mono)
• COMP : 1-knob compressor Threshold: +22 dBu to -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to
• 7 dB, Attack time: approx. 25 msec, Release time: approx. 300 msec
• EQ HIGH : Gain- +15 dB/-15 dB, Frequency: 10 kHz shelving
• EQ MID : Gain- +15 dB/-15 dB, Frequency: 2.5kHz peaking
• EQ LOW : Gain- +15 dB/-15 dB, Frequency: 100 Hz shelving
• PEAK LED : LED turns on when post EQ signal reaches 3 dB below clipping
• Level Meter : 2 x 7 -segment LED meter [PEAK, +10, +6, 0, -6, -10, -20 dB]
• Total harmonic distortion : 0.02 % @ +14dBu (20 Hz to 20kHz), GAIN knob: Min, 0.003 % @ +24dBu (1kHz), GAIN knob: Min
• Frequency response : +0.5 dB/-1.0 dB (20 Hz to 48 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min
• Equivalent input noise : -128 dBu (Mono Input Channel, Rs: 150Ω, GAIN knob: Max)
• Residual output noise : -102 dBu (STEREO OUT, STEREO LEVEL knob: Min)
• Crosstalk : -83 dB
• Power requirements: PA-10 (AC 38 VCT, 0.62A, Cable length = 3.6 m) or equivalent recommended by Yamaha
• Power consumption : 22.9 W
• Included Accessory : AC Adaptor, Owner’s Manual, Technical Specifications
• Optional Accessory: Mic Stand Adaptor BMS-10A
